CBHS-FL304 Hydraulic Gear Pump: Reliable & Efficient | Manufacturer Supply

변위:4 cc/회전

정격 압력:20 MPa (2900 psi)

최대 압력:25 MPa (3625 psi)

최대 속도:분당 3000회전

회전 방향:R: 오른쪽 (시계 방향)

브랜드:BXHS

제품 유형:유압 기어 펌프

제품 시리즈:CBHS-FL3 시리즈 유압 기어 펌프

포장 크기:20*30*20

총중량:9.00 kg

재고 상태: 재고 있음

943 이 제품을 찾아보시지 않겠습니까?

CBHS-FL304 Hydraulic Gear Pump: Reliable & Efficient | Manufacturer Supply

CBHS-FL304 Hydraulic Gear Pump: Reliable & Efficient | Manufacturer Supply

CBHS-FL304 Hydraulic Gear Pump: Reliable & Efficient | Manufacturer Supply drawing image

The CBHS-FL304 Hydraulic Gear Pump is a reliable and efficient pump designed for heavy-duty applications in various industries. It features a displacement of 10 cc/rev, a rated pressure of 20 MPa, and a rated speed of 2000 r/min, making it suitable for a wide range of construction and agricultural equipment.

CBHS-FL3 시리즈 유압 기어 펌프 매개변수
변위 10 cc/회전, 4 cc/회전, 20 cc/회전, 16 cc/회전, 14 cc/회전, 6 cc/회전
정격 압력 20 MPa (2900 psi)
최대 압력 25 MPa (3625 psi)
정격 속도 분당 2000회전
최대 속도 분당 3000회전
회전 방향 L: 왼쪽 (반시계 방향), R: 오른쪽 (시계 방향)
재질 알루미늄
구조 외부 기어 펌프
플랜지 버전 A-타원 플랜지
샤프트 유형 H: 직사각형 스플라인, X: 유선 스플라인, P: 평범한 키

The CBHS-FL304 Hydraulic Gear Pump is a high-performance pump designed for demanding applications in construction, agriculture, and industrial vehicles. It features an internal gear pump design with an aluminum body, ensuring durability and efficiency. The pump has a displacement of 10 cc/rev and a rated pressure of 20 MPa, providing strong hydraulic power for a variety of tasks. Its rated speed is 2000 r/min, with a maximum speed of 3000 r/min. The CBHS-FL304 is available with both left and right rotation options. It features an A-Oval flange and a plain key shaft, making it compatible with various equipment. This pump is ideally suited for telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, harvesters, and balers.
