DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type

제어 방식:전기 유압

스풀:1 스풀

정격 유량:분당 60리터 (15.8 US gpm)

최대 압력:315바 (4600 psi)

입구 포트:G1/2

출구 포트:G1/2

포트 크기:G1/2

브랜드:BXHS

제품 유형:구역 방향 밸브

제품 시리즈:DCV60 시리즈 구역 방향 밸브

Packagingsize:39*23*21

Grossweight:11.60 kg

재고 상태: 재고 있음

96 이 제품을 찾아보시지 않겠습니까?

DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type

DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type

DCV60 Series Electro-hydraulic Directional Control Valve 1 Spool Sectional Type drawing image

The DCV60 Series is a high-performance, single-spool electro-hydraulic directional control valve engineered for heavy-duty mobile applications. Featuring a 60 L/min flow rate and 350 bar pressure capacity, it offers precise control for construction, agricultural, and material handling equipment.

DCV60 시리즈 구역 방향 밸브 매개변수
제어 방식 수동, 공압, 전기 공압, 전기 유압, 유압, 유압 및 수동, 케이블, 조이스틱, 솔레노이드 및 수동, 솔레노이드 및 조이스틱, 수동 및 조이스틱, 전동기
스풀 1 스풀, 2 스풀, 3 스풀, 4 스풀, 5 스풀, 6 스풀, 7 스풀, 8 스풀, 9 스풀, 10 스풀, 11 스풀, 12 스풀
주변 온도 범위 -40°C to +80°C (-40°F to +176°F)
구조 유형 섹션 밸브
섹션 1 섹션, 2 섹션, 3 섹션, 4 섹션, 5 섹션, 6 섹션, 7 섹션, 8 섹션, 9 섹션, 10 섹션, 11 섹션, 12 섹션
작동 점도 범위 15 - 75 mm²/s (15 cSt to 75 cSt)
정격 유량 분당 60리터 (15.8 US gpm)
최대 압력 315바 (4600 psi), 350바 (5100 psi)
입구 포트 G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
출구 포트 G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
포트 크기 G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

As a leading manufacturer of hydraulic components, we specialize in high-precision directional control valves designed for demanding operational environments. Our DCV60 Series provides reliable performance for various machinery, including tractors, mini-excavators, and material handling vehicles. We are committed to supporting global partners through flexible cooperation models, including OEM, ODM, private labeling, and custom engineering services. Our factory-direct supply chain ensures consistent quality and competitive wholesale pricing for global distributors, wholesalers, and international traders. Whether you require standard inventory or specialized, application-specific configurations, our production team is equipped to meet your technical specifications with efficiency and professional support. We are actively seeking long-term partnerships with distributors, wholesalers, and trade companies worldwide to expand our market reach and deliver high-value hydraulic solutions to the construction and agricultural sectors.
