High-Performance P81 Valve for Demanding Hydraulic Applications

제어 방식:수동

스풀:1 스풀

정격 유량:분당 80리터 (21.2 US gpm)

최대 압력:19 MPa (2735 psi)

입구 포트:G1/2

출구 포트:G3/4

포트 크기:G3/4

브랜드:BXHS

제품 유형:로그 스플리터 밸브

제품 시리즈:P81 시리즈 로그 스플리터 밸브

포장 크기:27*16*12

총중량:4.80 kg

재고 상태: 재고 있음

1678 이 제품을 찾아보시지 않겠습니까?

High-Performance P81 Valve for Demanding Hydraulic Applications

High-Performance P81 Valve for Demanding Hydraulic Applications

High-Performance P81 Valve for Demanding Hydraulic Applications drawing image

The P81 Series Multiway Directional Valve is a high-performance hydraulic valve designed for demanding applications in industrial vehicles, particularly wood splitters. This manual control valve features a monoblock structure and delivers a rated flow of 80 L/min (21.2 US gpm) at a maximum pressure of 250 bar (3600 psi).

P81 시리즈 로그 스플리터 밸브 매개변수
제어 방식 수동
스풀 1 스풀
주변 온도 범위 -40°C to +80°C (-40°F to +176°F)
구조 유형 모노블록 밸브
섹션 1 섹션
작동 점도 범위 15 - 75 mm²/s (15 cSt to 75 cSt)
정격 유량 분당 80리터 (21.2 US gpm), 분당 95리터 (25.1 US gpm)
최대 압력 19 MPa (2735 psi)
입구 포트 G1/2
출구 포트 G1/2
포트 크기 G3/4

The P81 Series Multiway Directional Valve is a robust and reliable solution for controlling hydraulic systems in demanding industrial applications. This high-performance valve is specifically designed for wood splitters, offering superior control and efficiency. Its monoblock construction provides durability and strength, ensuring long-lasting performance. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), the P81 valve is capable of handling high-pressure hydraulic systems. The valve operates within a wide viscosity range (15 - 75 mm²/s) and can withstand temperatures from -40°C to +80°C. Its kick-out setting pressure is adjustable between 70~140bar (1015-2030psi), providing precise control and safety. The P81 Series Multiway Directional Valve is an ideal choice for manufacturers and users of industrial vehicles and equipment requiring a high-performance, reliable, and durable hydraulic valve solution.
