High-Pressure CBHC-2082 Hydraulic Gear Pump - 28 MPa (4061 psi) Performance

변위:80 cc/회전

정격 압력:20 MPa (2900 psi)

최대 압력:25 MPa (3625 psi)

최대 속도:분당 2500회전

회전 방향:양방향

브랜드:BXHS

제품 유형:유압 기어 펌프

제품 시리즈:CBHC 시리즈 유압 기어 펌프

포장 크기:22*22*25

총중량:16.30 kg

재고 상태: 재고 있음

433 이 제품을 찾아보시지 않겠습니까?

High-Pressure CBHC-2082 Hydraulic Gear Pump - 28 MPa (4061 psi) Performance

High-Pressure CBHC-2082 Hydraulic Gear Pump - 28 MPa (4061 psi) Performance

High-Pressure CBHC-2082 Hydraulic Gear Pump - 28 MPa (4061 psi) Performance drawing image

Discover the CBHC-2082 high-pressure hydraulic gear pump, offering 82 cc/rev displacement and up to 30 MPa maximum pressure. Built with durable cast iron and an SAE flange, this versatile pump is suitable for heavy-duty applications in construction, agriculture, and material handling, available for global distribution.

CBHC 시리즈 유압 기어 펌프 매개변수
변위 32 cc/회전, 40 cc/회전, 50 cc/회전, 63 cc/회전, 80 cc/회전, 100 cc/회전, 25 cc/회전, 110 cc/회전
정격 압력 16 MPa (2320 psi), 18 MPa (2610 psi), 28 MPa (4061 psi), 29 MPa (4206 psi)
최대 압력 30 MPa (4351 psi)
정격 속도 분당 2200회전
최대 속도 분당 2500회전
회전 방향 L: 왼쪽 (반시계 방향), R: 오른쪽 (시계 방향), 양방향
재질 주철
구조 외부 기어 펌프
플랜지 버전 SAE 플랜지
샤프트 유형 H: 직사각형 스플라인

As a leading **hydraulic product manufacturer**, we proudly present the **High-Pressure CBHC-2082 Hydraulic Gear Pump**, engineered for demanding global applications. This robust **external gear pump** features an 82 cc/rev displacement and handles rated pressures up to 29 MPa (4206 psi), with a maximum pressure capacity of 30 MPa (4351 psi). Designed for reliability, our **CBHC-2082 pump** boasts a durable **cast iron** structure, **SAE flange** version, and a **rectangle spline shaft (Type H)**, ensuring stable and efficient operation.

This versatile **hydraulic pump** is available in bidirectional, right, and left rotation options, making it suitable for a wide range of **heavy-duty applications**. It performs effectively in **material handling**, **construction and earth moving**, **agriculture**, and **industrial vehicles**. Specific **applicable models** include telehandlers, forklifts, all terrain cranes, aerial platforms, midi-excavators, wheel loaders, backhoe loaders, tractors, front-end loaders, harvesters, and waste compactors.

We offer comprehensive services including **manufacturing**, **OEM (Original Equipment Manufacturing)**, **ODM (Original Design Manufacturing)**, **private label**, and **custom hydraulic pump solutions**. Our **factory direct supply** ensures quality control and competitive pricing for all your **hydraulic system components**. We are actively seeking strong partnerships with **distributors**, **wholesalers**, **agents**, and **trade partners** worldwide to expand our reach for this **high-performance hydraulic pump** and other **factory wholesale** products. Partner with us for reliable, **high-quality hydraulic gear pumps** directly from the source.
