Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

제어 방식:수동

스풀:1 스풀

정격 유량:분당 40리터 (10.5 US gpm)

최대 압력:250바 (3600 psi)

입구 포트:G1/2

출구 포트:G1/2

포트 크기:G1/2

브랜드:BXHS

제품 유형:모노블럭 방향 제어 밸브

제품 시리즈:P40 시리즈 모노블럭 방향 제어 밸브

포장 크기:23*16*11

총중량:3.00 kg

재고 상태: 재고 있음

1051 이 제품을 찾아보시지 않겠습니까?

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve drawing image

The P40-G12-1OT Directional Valve is a high-performance, manual control, monoblock hydraulic valve designed for various applications in construction, agriculture, and industrial vehicles. It features a rated flow of 40 L/min and a maximum pressure of 250 bar, making it ideal for telehandlers, forklifts, cranes, stackers, and more.

P40 시리즈 모노블럭 방향 제어 밸브 매개변수
제어 방식 수동, 공압, 전기 공압, 전기 유압, 솔레노이드, 유압, 유압 및 수동, 케이블, 조이스틱, 솔레노이드 및 조이스틱, 수동 및 조이스틱, 솔레노이드 및 케이블
스풀 1 스풀, 2 스풀, 3 스풀, 4 스풀, 5 스풀, 6 스풀, 7 스풀
주변 온도 범위 -40°C to +80°C (-40°F to +176°F)
구조 유형 모노블록 밸브
섹션 1 섹션, 2 섹션, 3 섹션, 4 섹션, 5 섹션, 6 섹션, 7 섹션
작동 점도 범위 15 - 75 mm²/s (15 cSt to 75 cSt)
정격 유량 분당 40리터 (10.5 US gpm)
최대 압력 250바 (3600 psi)
입구 포트 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
출구 포트 G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
포트 크기 G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-1OT Directional Valve is a robust and reliable hydraulic valve designed for demanding applications. It features a single spool and a single section with manual control, providing precise flow control and directional switching. Its monoblock construction ensures high strength and durability. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve can handle a wide range of hydraulic systems. Its operating viscosity range of 15 - 75 mm²/s allows for use in various fluid conditions. The P40-G12-1OT is designed for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its rugged construction and wide operating temperature range of -40°C to +80°C make it suitable for use in challenging environments.
