Hydraulic Valve: SD5-G38 Model | Wholesale & Customization Available

제어 방식:수동

스풀:4 스풀

정격 유량:분당 45리터 (11.8 US gpm)

최대 압력:315바 (4600 psi)

입구 포트:G3/8

출구 포트:G3/8

포트 크기:G3/8

브랜드:BXHS

제품 유형:모노블럭 방향 제어 밸브

제품 시리즈:SD5 시리즈 모노블럭 방향 제어 밸브

포장 크기:22.5*23.5*12.5

총중량:9.90 kg

재고 상태: 재고 있음

954 이 제품을 찾아보시지 않겠습니까?

Hydraulic Valve: SD5-G38 Model | Wholesale & Customization Available

Hydraulic Valve: SD5-G38 Model | Wholesale & Customization Available

Hydraulic Valve: SD5-G38 Model | Wholesale & Customization Available drawing image

The SD5-G38 Hydraulic Two Way Valve is a high-performance, manual control valve designed for use in a variety of construction, material handling, and agricultural applications. This monoblock valve features a 4-section design, a 40 L/min rated flow, and a maximum pressure of 305 bar. It is suitable for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders.

SD5 시리즈 모노블럭 방향 제어 밸브 매개변수
제어 방식 수동, 공압, 전기 공압, 전기 유압, 솔레노이드, 유압, 유압 및 수동, 케이블, 조이스틱
스풀 1 스풀, 2 스풀, 3 스풀, 4 스풀, 5 스풀, 6 스풀, 7 스풀
주변 온도 범위 -40°C to +60°C (-40°F to +140°F)
구조 유형 모노블록 밸브
섹션 1 섹션, 2 섹션, 3 섹션, 4 섹션, 5 섹션, 6 섹션, 7 섹션
작동 점도 범위 15 - 75 mm²/s (15 cSt to 75 cSt)
정격 유량 분당 40리터 (10.5 US gpm)
최대 압력 305바 (4400 psi)
입구 포트 G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
출구 포트 G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
포트 크기 G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

The SD5-G38 Hydraulic Two Way Valve is a robust and reliable valve that is ideal for demanding applications. It is manufactured from high-quality materials and is designed to withstand a wide range of operating conditions. The valve features a manual control method, a 4-section design, and a monoblock structure. It has a rated flow of 40 L/min and a maximum pressure of 305 bar. The operating viscosity range is 15-75 mm²/s and the ambient temperature range is -40°C to +60°C. This valve is suitable for use in a variety of applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. We offer wholesale and customization options for this product.
