The Industrial-Grade Hydraulic Gear Pump is a highly customizable product designed for a wide range of applications in industries such as material handling, construction, earth moving, agriculture, and industrial vehicles. With its rugged cast iron construction and B-Square flange, this pump is built to withstand demanding operating conditions.
| CBHS-F5 시리즈 유압 기어 펌프 매개변수 | |
|---|---|
| 변위 | 32 cc/회전, 50 cc/회전, 63 cc/회전, 20 cc/회전 |
| 정격 압력 | 20 MPa (2900 psi) |
| 최대 압력 | 25 MPa (3625 psi) |
| 정격 속도 | 분당 2000회전 |
| 최대 속도 | 분당 2500회전 |
| 회전 방향 | L: 왼쪽 (반시계 방향), R: 오른쪽 (시계 방향) |
| 재질 | 주철 |
| 구조 | 외부 기어 펌프 |
| 플랜지 버전 | B-사각 플랜지 |
| 샤프트 유형 | H: 직사각형 스플라인, X: 유선 스플라인, P: 평범한 키 |
**Industrial-Grade Hydraulic Gear Pump: Customized Manufacturing and Distribution**
**Product Highlights:**
- Displacement: 32 cc/rev, 50 cc/rev, 63 cc/rev
- Rated Pressure: 20 MPa (2900 psi)
- Rated Speed: 2000 r/min
- Max Speed: 2200 r/min
- Rotation: L: Left (counter-clockwise), R: Right (clockwise)
- Structure: Internal Gear Pump
- Material: Cast Iron
- Flange Version: B-Square Flange
- Shaft Type: P: Plain Key, H: Rectangle Spline, X: Involute Spline
- Series: CBHS-F5 Series
- Application Area: MATERIAL HANDLING,CONSTRUCTION AND EARTH MOVING,AGRICULTURE,INDUSTRIAL VEHICLES
- Applicable Model: TELEHANDLER,FORKLIFT,ALL TERRAIN CRANE,STACKER,AERIAL PLATFORM,MOTOR GRADER,MIDI-EXCAVATOR,MINI-EXCAVATOR,SKID STEER LOADER,COMPACT WHEEL LOADER
**Key Features and Benefits:**
- **Customized Manufacturing:** Tailored to meet specific application requirements, ensuring optimal performance and efficiency.
- **High-Quality Materials:** Durable cast iron construction ensures longevity and reliability in demanding environments.
- **B-Square Flange:** Industry-standard mounting configuration for easy integration into existing systems.
- **Versatile Shaft Options:** Plain key, rectangle spline, and involute spline shaft types available to accommodate various drive requirements.
- **Wide Range of Applications:** Suitable for a variety of industrial applications, including material handling, construction, earth moving, agriculture, and industrial vehicles.
