Precision P51A646TEYR25-25 Hydraulic Gear Pump Components

변위:104.5 cc/rev

정격 압력:16 MPa (2320 psi)

최대 압력:17 MPa (2465 psi)

최대 속도:분당 2400회전

회전 방향:양방향

브랜드:BXHS

제품 유형:유압 기어 펌프

제품 시리즈:P51 시리즈 유압 기어 펌프

포장 크기:34*17*17

총중량:24.00 kg

재고 상태: 재고 있음

146 이 제품을 찾아보시지 않겠습니까?

Precision P51A646TEYR25-25 Hydraulic Gear Pump Components

Precision P51A646TEYR25-25 Hydraulic Gear Pump Components

Precision P51A646TEYR25-25 Hydraulic Gear Pump Components drawing image

High-performance P51 series bidirectional hydraulic gear pump with 104.5 cc/rev displacement, designed for heavy-duty industrial and mobile applications requiring reliable pressure up to 17 MPa.

P51 시리즈 유압 기어 펌프 매개변수
변위 104.5 cc/rev, 21 cc/rev, 41.8 cc/rev, 52.3 cc/rev, 62.7 cc/rev, 64.6 cc/rev
정격 압력 16 MPa (2320 psi)
최대 압력 17 MPa (2465 psi)
정격 속도 분당 2200회전
최대 속도 분당 2400회전
회전 방향 양방향
재질 주철
구조 외부 기어 펌프
플랜지 버전 A-타원 플랜지, ISO-4 장착 구멍, SAE 플랜지
샤프트 유형 X: 유선 스플라인

As a leading manufacturer of large-scale hydraulic solutions, we offer the Precision P51A646TEYR25-25 Hydraulic Gear Pump designed for versatility and durability. This P51 series component features a 104.5 cc/rev displacement and bidirectional rotation, making it ideal for complex hydraulic circuits. We provide comprehensive services including manufacturing, OEM, ODM, and customized branding to meet your specific technical requirements. Our factory direct supply ensures competitive wholesale pricing for bulk orders. We are actively seeking long-term partnerships with distributors, wholesalers, regional agents, and international traders to expand our global presence. With a rated speed of 600 r/min and a maximum pressure capacity of 17 MPa, this rugged cast iron pump is engineered for consistent performance. Partner with us for reliable factory wholesale access to premium hydraulic gear pumps and components.
