The Sectional Directional Hydraulic Valve: DLS180 Micro Switch Manual 4 Spool is a high-performance valve designed for use in a wide range of hydraulic systems. With a rated flow of 160 L/min and a maximum pressure of 350 bar, this valve is capable of handling even the most demanding applications. The manual control and 4 spool design provide precise and reliable control over the flow of hydraulic fluid.
| SDS180 시리즈 구역 방향 밸브 매개변수 | |
|---|---|
| 제어 방식 | 수동, 유압 |
| 스풀 | 1 스풀, 2 스풀, 3 스풀, 4 스풀, 5 스풀, 6 스풀, 7 스풀 |
| 주변 온도 범위 | -40°C to +80°C (-40°F to +176°F) |
| 구조 유형 | 섹션 밸브 |
| 섹션 | 1 섹션, 2 섹션, 3 섹션, 4 섹션, 5 섹션, 6 섹션, 7 섹션, 8 섹션, 9 섹션, 10 섹션 |
| 작동 점도 범위 | 12 - 400 mm²/s (12 cSt to 400 cSt) |
| 정격 유량 | 분당 160리터 (42.2 US gpm) |
| 최대 압력 | 315바 (4600 psi), 350바 (5100 psi) |
| 입구 포트 | G3/4, G1, SAE 12 |
| 출구 포트 | G1, SAE 16 |
| 포트 크기 | G3/4, G1, SAE 12 |
**Sectional Directional Hydraulic Valve: DLS180 Micro Switch Manual 4 Spool**
**Control Method:** Manual
**Section:** 4 Section
**Structure Type:** Sectional valve
**Rated Flow:** 160 L/min (42.2 US gpm)
**Max Pressure:** 350 bar (5100 psi)
**Operating Viscosity Range:** 12 - 400 mm²/s (12 cSt to 400 cSt)
**Series:** SDS180 Series
**Application Area:** MATERIAL HANDLING, CONSTRUCTION AND EARTH MOVING, AGRICULTURE, INDUSTRIAL VEHICLES
**Applicable Model:** TELEHANDLER, FORKLIFT, ALL TERRAIN CRANE, STACKER, AERIAL PLATFORM, MOTOR GRADER, TELEHANDLER, MIDI-EXCAVATOR, MINI-EXCAVATOR, SKID STEER LOADER
The Sectional Directional Hydraulic Valve: DLS180 Micro Switch Manual 4 Spool is a versatile and reliable valve that is well-suited for a wide range of applications. Its compact design and lightweight construction make it easy to install and maintain, while its durable construction ensures long-lasting performance.
