The ZT20 Series Hydraulic Control Valve with Joystick is a high-performance, reliable directional valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. Featuring a monoblock structure, it delivers a rated flow of 100 L/min and a maximum pressure of 250 bar, making it suitable for demanding operations.
| ZT20 시리즈 유압 제어 밸브 매개변수 | |
|---|---|
| 제어 방식 | 수동, 케이블, 조이스틱, 수동 및 조이스틱 |
| 스풀 | 1 스풀, 2 스풀, 3 스풀, 4 스풀, 5 스풀, 6 스풀 |
| 정격 유량 | 분당 100리터 (26.5 US gpm) |
| 최대 압력 | 250바 (3600 psi) |
| 입구 포트 | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| 출구 포트 | G1/2, G3/4, M22×1.5, M27×2.0, SAE 8, SAE 10, 1/2 NPT, 3/4 NPT |
| 포트 크기 | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| 섹션 | 1 섹션, 2 섹션, 3 섹션, 4 섹션, 5 섹션, 6 섹션 |
| 구조 유형 | 모노블록 밸브 |
| 주변 온도 범위 | -40°C to +80°C (-40°F to +176°F) |
| 작동 점도 범위 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
The ZT20 Series Hydraulic Control Valve with Joystick is a 2-section, manual control monoblock valve designed for reliable and efficient hydraulic operations. With a rated flow of 100 L/min (26.5 US gpm) and a maximum pressure of 250 bar (3600 psi), it is capable of handling heavy loads in a variety of demanding applications. The valve features a 2-spool design and operates within a viscosity range of 15-75 mm²/s (15 cSt to 75 cSt). Its robust construction ensures long-lasting performance even in extreme temperatures ranging from -40°C to +80°C (-40°F to +176°F). Designed for a wide range of applications, the ZT20 Series valve is ideal for telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
